Asrock NUC BOX-1220P Low Profile (Slimline) Black i3-1220P 3.3 GHz
Product no.: 90PXG9K0-00EAY100
| Processor | |
| Built-in processor: |  |
| Processor manufacturer: | Intel |
| Processor family: | IntelŪ Core i3 |
| Processor generation: | 12th gen IntelŪ Core i3 |
| Processor model: | i3-1220P |
| Processor frequency: | 3.3 GHz |
| Processor cores: | 2 |
| Processor boost frequency: | 4.4 GHz |
| Processor cache: | 12 MB |
| CPU configuration (max): | 1 |
| Memory | |
| Memory slots type: | SO-DIMM |
| Number of memory slots: | 2 |
| Maximum internal memory: | 64 GB |
| Supported memory clock speeds: | 3200 MHz |
| Supported memory types: | DDR4-SDRAM |
| Memory channels: | Dual-channel |
| Storage | |
| Supported storage drive types: | HDD & SSD |
| Storage drive sizes supported: | 3.5,M.2 |
| SSD form factor: | M.2 |
| Graphics | |
| On-board graphics card: | |
| On-board graphics card model: | IntelŪ UHD Graphics |
| Audio | |
| Built-in speaker(s): |  |
| Network | |
| Ethernet LAN: | |
| Wi-Fi: | |
| Wi-Fi standards: | Wi-Fi 6E (802.11ax) |
| Bluetooth: | |
| Bluetooth version: | 5.2 |
| Ports & interfaces | |
| HDMI ports quantity: | 1 |
| Ethernet LAN (RJ-45) ports: | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: | 2 |
| HDMI version: | 2.0b |
| DisplayPorts quantity: | 1 |
| DisplayPort version: | 1.4a |
| Combo headphone/mic port: | |
| Number of SATA III connectors: | 1 |
| Expansion slots | |
| Number of M.2 (M) slots: | 2 |
| Design | |
| Chassis type: | Low Profile (Slimline) |
| Product colour: | Black |
| Product type: | PC barebone |
| On/off switch: | |
| LED indicators: | |
| Cable lock slot: | |
| Performance | |
| Motherboard form factor: | ATX |
| BIOS type: | AMI |
| BIOS memory size: | 256 Mbit |
| Trusted Platform Module (TPM): | |
| Trusted Platform Module (TPM) version: | 2.0 |
| Audio chip: | Realtek ALC233 |
| Processor special features | |
| Embedded options available: | |
| Intel Virtualization Technology for Directed I/O (VT-d): | |
| Intel VT-x with Extended Page Tables (EPT): | |
| Intel Flex Memory Access: | |
| Execute Disable Bit: | |
| Intel Virtualization Technology (VT-x): | |
| Technical details | |
| Sustainability certificates: | CE, Federal Communications Commission (FCC) |
| Power | |
| AC adapter output voltage: | 12 - 19 V |
| Operational conditions | |
| Operating temperature (T-T): | 0 - 40 °C |
| Storage temperature (T-T): | -40 - 85 °C |
| Operating relative humidity (H-H): | 5 - 90% |
| Storage relative humidity (H-H): | 5 - 90% |
| Weight & dimensions | |
| Width: | 110 mm |
| Depth: | 47.9 mm |
| Height: | 117.5 mm |
| Weight: | 1 kg |
| Other features | |
| Internal memory: | 64 GB |
Price:
0,00 €
19 % VAT incl. excl. Shipping costs
