- Details
M2 Mini-Gray
Aluminium/Steel
Mini-ITX Case
Luxurious Esthetic
328(D) x 150(W) x 235(H) mm
2.8 kg
Sophisticated Aluminium Processing
CNC Digital Cutting / Edge Rounding cutoff.
Efficient Cooling Design
Optimized airflow through the top and ventilated acrylic panels.
Dual-Sided Premium Acryl Panels
Premium 4T-thick acryl provides strong interior protection while the perforation offers smooth air ventilation. Easy to use side panels with thumb screws.
Smart I/O Port
- Power Button
- USB 3.0 Port
- USB 3.1 Gen2 Type-C
Pre-Installed PCIe3.0 Riser Cable
- Connecter fits most mounts and cases
- Slide type PCI-e holding tap
- Electromagnetic interference (EMI) shielding ensures maximum performance
- 24K-Gold plated contacts for best connectivity and long life
- PCB protector included
- Five-wire banded construction allows for full flexibility
Specifications
Model: M2 mini
Case Form Factor: Mini-ITX Case
Dimension: 328(D) x 150(W) x 235(H)mm
Weight: 2.8kg
Materials: Aluminum, Steel, Acrylic
Motherboard Support: Mini-ITX
Maximum VGA Length: 295mm
Maximum CPU Cooler Height: 60mm
Maximum PSU Length: SFX, SFX-L
PCI Expansion Slots: 2
Drive Bays: SSD/ HDD 2 x 2.5"
Fan Support Top: 1 x 80mm
Fan(s) Included Top: 1 x 80mm
Radiator Support: -
I/O Ports: 1 x USB3.0, 1 x USB3.1 Gen2 Type-C, Power Button(LED)
Productcode: M2 Mini-Gray
| Design | |
| Form factor: | Mini Tower |
| Type: | PC |
| Product colour: | Grey |
| Supported motherboard form factors: | Mini-ITX |
| Material: | Acrylic, Aluminium, Steel |
| Number of 2.5" bays: | 2 |
| Number of storage drives supported: | 2 |
| Number of expansion slots: | 2 |
| Side window: | Yes |
| Suitable for: | Gaming |
| Tempered glass panel(s): | No |
| Transport wheels: | No |
| Reset button: | No |
| On/off button: | Yes |
| RGB control button: | No |
| LED indicators: | Power |
| Maximum CPU cooler height: | 6 cm |
| Maximum graphics card length: | 29.5 cm |
| Maximum PSU length: | 13 cm |
| Power supply | |
| Power supply included: | No |
| Power supply location: | Front |
| Number of power supply units: | 1 |
| Supported power supply form factors: | SFX |
| Ports & interfaces | |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: | 1 |
| Audio input: | No |
| Audio output: | No |
| Cooling | |
| Top fans installed: | 1x 80 mm |
| Number of top fans supported (max): | 1 |
| Top fans diameters supported: | 80 mm |
| Storage | |
| Supported HDD sizes: | 2.5" |
| HDD/SSD combo cage: | Yes |
| SSD form factor: | 2.5" |
| Number of HDDs supported: | 2 |
| Weight & dimensions | |
| Width: | 150 mm |
| Depth: | 328 mm |
| Height: | 235 mm |
| Weight: | 3.1 kg |
| Packaging data | |
| Cables included: | PCIe |
| Other features | |
| I/O ports: | 1 x USB3.0, 1 x USB3.1 Gen2 Type-C, Power Button(LED) |
