Secure storage for your businessBusiness-readyOver 3,500/1,700 MB/s seq. read/write, built-in 10GbE, and up to 216 TB raw storage before expansion.Flexible configurationAdd 12 extra drive bays, 1/10/25GbE ports, and SSD cache volumes whenever needed.Versatile applicationsBack up 300 endpoints, manage 50 IP cameras, or safely sync and share files between devices and sites.Faster and more responsiveThe RS2423+/RS2423RP+ offer exceptional performance with over 155K/79K random read/write IOPS and up to 3,500/1,700 MB/s sequential read/write throughput.1 They are the perfect cost-effective file management and sharing solution for SMBs and come equipped with advanced backup capabilities designed for businesses with expanding data needs.Designed for reliabilityThe RS2423+ and RS2423RP+ come with one 10GbE RJ-45 port and two Gigabit RJ-45 ports, which can be bonded with Link Aggregation to enable automatic network failover and load balancing.Two RS2423+/RS2423RP+ units can be paired using Synology High Availability to form a reliable active-passive server cluster, maximizing service uptime.The RS2423RP+ also features redundant and hot-swappable power supply units to protect service continuity in case there are issues with one power source.Room for expansionEasily adjust the 2U 12-bay RS2423+/RS2423RP+ to match the usage of your environment, whether it needs performance, faster networking, or higher storage capacity.Versatile storage for businessesThe RS2423+/RS2423RP+ are ideal for small to medium-sized businesses and branch offices seeking a high-performing, reliable, and cost-efficient storage solution for file management, data backup, and surveillance.Intuitive storage for on-site and remote teamsProvide secure and convenient cross-platform file access, sharing, and synchronization across multiple locations.Enable efficient collaboration with Synology DriveSynology Drive provides remote data access, synchronization, on-demand file restoration, and backup via handy desktop and mobile applications. Multi-platform supportAccess personal and shared data from mobile apps, desktop clients, web browsers, or another Synology system. Any changes you make are automatically synced to other devices as soon as they are connected.Collaborate in real timeEnable concurrent editing of documents, spreadsheets, and slides with Synology Office, with support for conversion to and from Microsoft Word, Excel, PowerPoint, and OpenDocument files. Connect teams with Hybrid ShareUse Hybrid Share to store large sets of data in the cloud, leveraging the large bandwidth of our data centers to stream requested files to local NAS deployed at the branch offices.Reliable data access on demandWith Hybrid Share-enabled folders, remote teams retain full access to the most up-to-date files while benefiting from a reduced local storage footprint and lower bandwidth usage.Local caching of most-used dataFrequently-accessed files are kept on the local NAS, allowing users to access them at LAN speeds. Files and folders can also be pinned manually to prevent them from being replaced when the cache is full.Design an effective backup strategy to maximize data and system availability with a host of native and license-free solutions.Endpoint, VM, and NAS/SAN protectionSecurely back up Windows, Mac, and Linux endpoints, Synology servers, and VMware® and Hyper-V® virtual machines with Active Backup for Business.Microsoft 365 and Google WorkspaceCentralize backups of Microsoft 365 and Google Workspace data to protect cloud data from accidents and simplify compliance with data retention policies. Schedulable backups, flexible file versioning, and block-level deduplication ensure flexibility and savings in terms of storage and bandwidth consumption.Hyper BackupBack up files, LUNs, installed applications, and system configurations to destinations including Synology C2 Storage,5public cloud platforms, USB devices, file servers, local folders, and other Synology systems.Set and forget backup tasks with regular schedules, enhance security with granular user permissions and encryption, keep backup sizes small with built-in deduplication, and restore data flexibly with multi-versioning.Snapshot ReplicationSnapshot Replication enables configurable point-in-time snapshots of shared folders and VM storage with an RPO as low as 5 minutes and recovery within seconds. Smart and scalable surveillanceLeverage flexible deployment options, intuitive management capabilities, and advanced video analytics to secure your premises.Wide device compatibilityConnect up to 50 IP cameras from a selection of over 8,300 validated models thanks to Synology Surveillance Station s wide camera compatibility.Multi-platform convenienceMonitor live streams or watch recordings from web browsers, desktop clients, or the DS cam mobile app.Secure and private storageFootage is stored locally for easier compliance with data protection regulations and further protected from unauthorized access with industry-standard AES-256 encryption.Assisted camera deploymentAutomatically locate new cameras within a set IP range, and configure units in batch via spreadsheet import or replicating settings to new cameras.Centralized management and monitoringStay on top of your deployment by previewing triggered events directly on multi-floor or multi-location maps, with online map integration for Google Maps and OpenStreetMap.Time-saving video analyticsTake advantage of intelligent monitoring features such as motion detection, no-idle zones, foreign object detection, and anomaly detection that cater to common surveillance scenarios.Flexible monitoring of multiple locationsWorks best with Synology drivesEnjoy high sustained performance and reliability with enterprise-grade drives designed for Synology NAS, featuring built-in data protection.Works best with Synology drivesTake advantage of a host of native productivity, management, and security solutions available in the web-based Synology DSM operating system.Central Management SystemConveniently manage your fleet of Synology NAS from a centralized console.SecurityShield your Synology NAS from the most sophisticated threats with industry-leading security solutions.Synology High AvailabilityReal-time system-level protection with automatic failover mechanism to maximize service availability.Get extra protection with Extended Warranty PlusExtend the standard 3-year hardware warranty8 of your RS2423(RP)+ with 2 more years of Synology-certified support and premium services that help you recover faster in the event of disaster.
| Storage | |
| Storage drives installed: |  |
| Number of storage drives supported: | 12 |
| Installed storage drive type: | |
| Supported storage drive types: | HDD & SSD |
| RAID support: |  |
| Supported storage drive interfaces: | Serial ATA |
| Storage drive sizes supported: | 2.5,3.5" |
| RAID levels: | 0, 1, 5, 6, 10, JBOD |
| Online RAID migration: | |
| Online RAID expansion: | |
| Hot-swap drive bays: | |
| Supported file systems: | BTRFS, Fat, HFS+, NTFS, exFAT, ext3, ext4 |
| Processor | |
| Processor family: | AMD Ryzen |
| Processor manufacturer: | AMD |
| Processor model: | V1780B |
| Processor frequency: | 3.35 GHz |
| Processor boost frequency: | 3.6 GHz |
| Processor cores: | 4 |
| Number of processors supported: | 1 |
| Memory | |
| Internal memory: | 8 GB |
| Internal memory type: | DDR4 |
| Maximum RAM supported: | 32 GB |
| Memory slots: | 2 |
| Memory form factor: | UDIMM |
| ECC: | |
| Network | |
| Ethernet LAN: | |
| Ethernet LAN data rates: | 10,100,1000,10000 Mbit/s |
| Ethernet LAN data rate supported (max): | 10000 Mbit/s |
| Copper ethernet cabling technology: | 10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T |
| iSCSI support: | |
| Wake-on-LAN ready: | |
| Link aggregation: | |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports: | 3 |
| USB port: | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 2 |
| PCI Express x8 (Gen 3.x) slots: | 1 |
| Design | |
| Chassis type: | Rack (2U) |
| Cooling type: | Active |
| Product colour: | Black, Grey |
| Number of fans: | 3 fan(s) |
| Fan diameter: | 6 cm |
| LED indicators: | |
| Built-in display: | |
| Built-in speaker(s): | |
| Performance | |
| Type: | NAS |
| Device class: | Small & Medium Business |
| Backup function: | |
| Backup features: | Cloud, iSCSI LUN |
| Multilingual support: | |
| Noise level: | 52.3 dB |
| Card reader integrated: | |
| Snapshot: | |
| Management protocols: | SNMP |
| Security algorithms: | AES |
| Access Control List (ACL): | |
| Built-in FTP server: | |
| Browser supported: | Google Chrome Firefox Microsoft Edge Safari |
| System log: | |
| Software | |
| Operating system installed: | DiskStation Manager |
| Operating system version: | 7.1.1 |
| Power | |
| Power supply location: | Built-in |
| Power supply unit (PSU) capacity: | 500 W |
| Number of power supply units: | 1 |
| Redundant power supply (RPS) support: | |
| Power consumption (typical): | 119.95 W |
| AC input voltage: | 100 - 240 V |
| AC input frequency: | 50 - 60 Hz |
| Weight & dimensions | |
| Width: | 482 mm |
| Depth: | 562 mm |
| Height: | 88 mm |
| Weight: | 11.5 kg |
| Packaging content | |
| External power adapter: | |
| Cables included: | AC |
| Power cables quantity: | 1 |
| Rack mount kit: | |
| Technical details | |
| Sustainability compliance: | |
| Sustainability certificates: | CE, RoHS |
| Operational conditions | |
| Operating temperature (T-T): | 0 - 35 °C |
| Operating relative humidity (H-H): | 5 - 95% |
| Storage temperature (T-T): | -20 - 60 °C |
| Certificates | |
| Certification: | FCC BSMI VCCI RCM UKCA EAC CCC KC UL |
