Products description
| Processor | |
| Processor manufacturer: | Intel |
| Processor socket: | LGA 1200 (Socket H5) |
| Compatible processor series: | Intel® Xeon® |
| Intel Xeon series: | E-2300 |
| Memory | |
| Supported memory types: | DDR4-SDRAM |
| Number of memory slots: | 4 |
| Maximum internal memory: | 32 GB |
| Memory slots type: | DIMM |
| Memory voltage: | 1.2 V |
| ECC: |  |
| Non-ECC: | |
| Supported memory clock speed (max): | 2666 MHz |
| Storage controllers | |
| Supported storage drive interfaces: | M.2, SATA |
| RAID support: | |
| RAID levels: | 0, 1, 5, 10 |
| Graphics | |
| Graphics card family: | ASPEED |
| Graphics card: | AST2500 |
| On-board graphics card model: | Aspeed AST2500 |
| On-board graphics card memory: | 256 MB |
| Internal I/O | |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors: | 1 |
| Network | |
| Wi-Fi: |  |
| Ethernet LAN: | |
| Ethernet interface type: | Gigabit Ethernet |
| LAN controller: | Intel I210 |
| Features | |
| Component for: | PC |
| Motherboard form factor: | micro ATX |
| Motherboard chipset family: | Intel |
| Motherboard chipset: | Intel C252 |
| Expansion slots | |
| PCI Express x1 (Gen 3.x) slots: | 1 |
| PCI Express x4 (Gen 4.x) slots: | 1 |
| PCI Express x16 (Gen 4.x) slots: | 1 |
| BIOS | |
| BIOS type: | UEFI AMI |
| ACPI version: | 6.2 |
| System Management BIOS (SMBIOS) version: | 3.3 |
